Advanced GPS Speaker Microphone

Built-in joystick controller
Scroll through menus to select individual screens and functions using the RedHawk SA's built-in joystick controller.

RedHawk

 GPS Speaker Mic with LCD for Icom Radios

Software
Maptech Navigator Pro with terrain navigator Pro Team Tracker Upgrade (for US only). ESRI ARC
RedHawk SA Upgrade.

Additional Features

  • Locate, poll and set a course, and navigate to a field unit
  • See tracks made by other field units in relation to your position, and set a course
  • Download all tracks from the unit via USB cable should you need to transfer data to a PC
  • Access GIS information for all users on the same radio channel that are in the same group
  • See asset and field unit/resource location, speed, heading, directioin and altitude
  • See all the tracks made by other users showing search areas covered or travelled
  • See the relative distance of a field unit as it relates to the user
  • Set a course to a remote user, once in motion calculate the estimated time of arrival and distance to be travelled
  • Poll a unit: If a field unit has not been heard from, send a command to receive and update the info

  Features

Manage field assets, resources and incidents better by integrating RedHawk SA into your current communications system.




P25 and analog

  • Signal encryption through the radio
  • Send and receive text messages
  • More accurate GPS field asset location
  • Store, send and GOTO waypoints & users
  • Built-in, rechargeable 18 hour battery

  Specifications

General

  • Water resistant
  • IP54 water resistant. Okay to use in the rain.
  • 2.5 mm ear phone jack    Using an earpiece with the unit silences the unit's built-in speaker.
  • Compass    Built-in electronic compass for navigation to field units and set/received waypoints.
  • Display    A 120 × 140 trasnsreflective LCD monochrome grayscale display – highly valuable, even in sunlight.
  • GPS receiver chip    High sensitivity Atmel® GPS receiver chip set with built-in antenna.
  • Dimensions    59 (W) × 114 (H) × 30 (D) mm;
  • 2.32" (W) × 4.48" (H) × 1.18" (D)
  • Power supply voltage
  • Powered by a 3.7V / 1200mAH Li-Polymer battery that is recharged via USB connection from the mic to a PC, or 110/240 to 5 VDC, or 12 VDC to 5 VDC cigarette lighter adapter accessory. May be powered by the Icom radio itself.
  • Battery life    Long battery life: 18-20 hours with LCD backlight off.
  • Temperature range    -35° to 55° C (-31° to 136° F)
  • Weight    115g (4.16 oz) with lithium ion battery (approx.)
