IDAS™ digital mode operation
The IC-F3210D series provides NXDN™ CAI-based IDAS digital mode operation. It is compatible with IDAS multi-site and single-site trunking and IDAS multi-site conventional.
Easy to hear in noisy areas
The built-in bridge-tied load (BTL) amplifier delivers a powerful 800mW* audio output from the large 45mm speaker. In addition, the digital modulation provides distinct clarity even at the fringes of the communication range.
*Typical with internal speaker.
Channel announcement
When you rotate the channel knob, the radio announces the channel number. Convenient for making radio adjustments without having to look at the radio.
Longer operating time
The Li-Ion battery pack, BP-265 (7.4V, 2000mAh typ.), provides 17.5/16 hours* of operating time. Even when used with the BP-264, the radio offers 12/11 hours* of operating time.
*VHF/UHF, Tx:Rx:Standby=5:5:90. Power save function ON.
Weather resistant, military rugged
While the radio is compact and light weight, the radio is tested to dust protection and water resistant equivalent to IP54 and 11 categories of MIL-STD-810 environmental tests. In short, the IC-F3210D series is built rugged!
Internal VOX capability
The radio has the internal VOX capability for hands-free operation. Optional compatible headset with plug adapter cable OPC-2004 can be used with the radio. Also, the VOX gain and VOX delay time are adjustable.
General
Frequency coverage
IC-F3210D 136-174 MHz
IC-F3210D 400-470 MHz 450-512 MHz
Number of channels 16 channels
Type of emission 16K0F3E* / 11K0F3E/8K50F3E / 4K00F1E / F1D
Channel spacing 25* / 15 / 12.5 / 6.25 kHz
Power supply requirement 7.5V DC nominal
Current drain
Tx High (VHF)
Rx Max. audio
Standby
F3210D
1.3A
400mA (internal SP)
90mA (digital mode) F4210D
1.3A
400mA (internal SP)
100mA (digital mode)
Antenna impedance 5OΩ
Operating temperature range
-30°C to +60°C; -22°F to +140°F (radio only)
Dimensions (proj. not included) 58(cW) × 111.5(H) × 36.5(D) mm; 2.28×4.39×1.44in (with BP-265)
Weight 320g; 11.3oz (With MB-124, BP-265 & antenna)
Applicable U.S. Military Specifications and IP Rating
Standard MIL 810 F
Method Proc
Low Pressure 500.5 I, II
High Temp. 501.5 I, II
Low Temp. 502.5 I, II
Temp. Shock 503.5 I-C
Solar Radiation 505.5 I
Rain 506.5 I, III
Humidity 507.5 II
Salt Fog 509.5 –
Dust Blowing 510.5 I
Vibration 514.6 I
Shock 516.6 I, IV
Also meets equivalent MIL-STD-810-C, -D -E and -F.
Ingress Protection Standard (IC-F3210D, F4210D with BP-265)
Dust and water – IP54 (dust-protection and water resistant)
Extend your Communication Reach with IDAS™ Multi-Site trunking
IC-F3210D / IC-F4210D
Roaming scan
In the multi-site trunking mode, if the signal condition worsens as the radio user moves, the roaming scan automatically finds a new site to retain the communication link and quality.
IDAS™ digital mode features
PTT ID (TX)
Block decode
Radio check (RX)
Call alert
Emergency
GPS (TX with HM-171GP)
Individual/Group call
RAN (Radio Access Number)
Stun/kill/revive (RX)
Remote monitor (RX)
Digital voice scrambler
ATB (All Trunks Busy) ring back
*TX: Transmit, RX: Receive
Other features
CTCSS/DTCS encode/decoder*
Low battery alert
3-color LED
Time out timer
Lone worker function
Forced narrow function*
2-step power save
PC programmable
Voting Scan
Talk around function
No emergency in analog mode
Surveillance function
(* = analog only)
Transmitter
Output power (at 7.5V DC) F3210D: 5W, 2W, 1W (hi, L2, L1)
F4210D: 4W, 2W, 1W (Hi, L2, L1)
Max. frequency deviation ±5.0 kHz (wide)
±2.5 kHz (narrow)
Frequency stability
±1.0ppm
Spurious emissions F3210D: 75/71dB typ. (W/N)
F4210D: 75dB typ.
FM Hum and noise F3210D: 52/46dB typ. (W/N)
F4210D: 50/44dB typ. (W/N)
Audio harmonic distortion
0.5/0.8% typ. (AF 1kHz 40% deviation, W/N)
FSK Error
2% typ.
External microphone connector 3-conductor 2.5 (d) mm (1⁄10")⁄2.2Ω
Receiver
Sensitivity
(at 12dB SINAD)
(at 5% BER)
F3210D
0.23μV typ.
0.18μV typ. F4210D
0.22μV typ.
0.18μV typ.
Adjacent channel selectivity F3210D: 77/71dB typ. (W/N/D)
F4210D: 74/67/58dB typ. (W/N/D)
Spurious response rejection F3210D: 91dB typ.
F4210D: 80dB typ.
Intermodulation rejection 75/75/70dB typ. (W/N/D)
Hum and noise 48/42dB typ. (W/N)
Audio output power (at 5% distortion)
Internal SP (with 12Ω load)
External SP (With 8Ω load) 800mW typ. (Internal SP, 12Ω load)
400mW typ. (External SP, 8Ω load)
External speaker connector 2-conductor 3.5 (d) mm (1⁄8")⁄8Ω
Measurements made in accordance with EAIA-152-C/204D or TIA-603.
All stated specifications are subject to change without notice or obligation.
