Optional GPS Speaker-Microphone
With the optional GPS speaker-microphone, HM-171GPW, GPS position data can be attached to a voice or data transmission such as responding a GPS request status call.
Easy to Hear in a Noisy Environment
The large 36mm speaker of the transceiver provides clear 800mW* audio. The built-in BTL amplifier increases the audio output power and delivers loud and intelligible voice to a radio operator working in noisy environments.
*Typical with internal speaker.
Built-in 2-Tone and 5-Tone (Analog mode)
The IC-F1000D/F2000D has built-in 2-Tone, 5-Tone, CTCSS and DTCS signaling capability for analog mode group communication and selective calling. The IC-F1000D/F2000D can be used as an analog transceiver ready for future digital migration.
Long-Lasting Battery Pack
The large capacity waterproof battery pack, BP-280 (2400mAh typ.), provides 18 hours of operating time*. The supplied rapid charger BC-213* charges the BP-280 in 3.5 hours.
*Tx: Rx: Standby=5:5:90. Power save function ON. BC-213 may be not supplied depending on version.
Other features
DTMF autodial memories
MDC 1200 functions: PTT ID, emergency call, radio check (RX) and stun/revive (RX)
Surveillance function
Escalating alarm
VOX capability for hands-free operation
Channel announcement function
Red emergency switch on the top panel
Supplied accessories
May vary depending on version.
Battery pack, BP-280
Belt clip, MB-133
Antenna
Specifications
Features
IDAS™ VHF/UHF Digital & Analog Portable Two-Way Radios
IDAS™ Digital Mode Operation
The IC-F1000D/F2000D can program Type-D single- site trunking and digital conventional modes as well as analog mode per channel. The IDAS digital mode employs 4-level FSK modulation and the NXDN™ common air interface, offering true 6.25kHz spectrum efficiency, higher security and better audio clarity – even at the fringes of the communication range.
The following IDAS features are programmable:
PTT ID (TX)
Individual/group calls
Radio check (RX)
Stun/Kill/Revive (RX)
Remote monitor (RX)
Emergency (TX)
Call alert (RX)
Digital voice scrambler (15-bit)
Status Call (Power ON/OFF status and GPS request)
Voting scan for multi-site conventional operation TX: Transmit, RX: Receive
Intelligent Emergency Functions
To assist in worker safety, the IC-F1000D/F2000D has three emergency related functions: motion detection, man down and lone worker functions. If one of these functions are activated, the transceiver automatically enters an emergency phase and starts counting down to send an emergency signal. The built-in motion sensor detects its position and states motion and non-motion.
IP67 Waterproof and Dust-tight Protection
While the body is compact, the IC-F1000D/ F2000D has rugged construction providing superior protection against water (1m depth for 30 minutes), dust, sand, mud and other objects. The radio is also tested to MIL-STD 810 specifications. It can withstand harsh use.
Slim, Compact and Lightweight
The IC-F1000D/F2000D has a compact 52.2×111.8×30.3mm body and weighs only 260g (with BP-280 battery pack and belt clip). It’s easy to carry around anywhere.
General
Frequency coverage (MHz)
IC-F1000D
136–174MHz IC-F2000D
360–400MHz (EXP)
400-470MHz (USA
450-512MHz (USA)
450-520MHz (AUS)
Number of channels
IC-F1000D
16 channels IC-F2000D
16 channels
Type of emissions
IC-F1000D
16K0F3E, 11K0F3E,
8K50F3E, 4K00F1E/D IC-F2000D
16K0F3E, 11K0F3E,
4K00F1E/D
Channel spacing
IC-F1000D
30KHz, 15KHz, 6.25KHz
25KHz, 12.5KHz, 6.25KHz IC-F2000D
25KHz, 12.5KHz, 6.25KHz
Power supply requirement 7.5V DC nominal
Current drain
TX High
RX Max. auidio/ Sandby
IC-F1000D
1.3A
400mA (Internals SP) / 110mA IC-F2000D
1.4A
400mA (Internal SP) / 110mA
Antenna impedance 50Ω
Operating temperature range -30°C to 60°C; –22°F to +140°F (radio specifications)
Dimensions (W×H×D)
(Projections not included) 52.2×111.8×30.3 mm; 2.06×4.4×1.19 in (With BP-280)
Weight 260g; 9.17oz (With MB-133 and BP-280)
Applicable U.S. Military Specifications
Icom makes rugged products that meet MIL-STD requirements and strict environmental standards as follows.
Standard MIL 810 F
Method Proc
Low Pressure 500.5 I, II
High Temp. 501.5 I, II
Low Temp. 502.5 I, II
Temp. Shock 503.5 I
Solar Radiation 505.5 I
Rain Blowing/Drip 506.5 I, III
Humidity 507.5 –
Salt Fog 509.5 –
Dust Blowing 510.5 I
Immersion 512.5 I
Vibration 514.6 I
Shock 516.6 I, IV
Also meets equivalent MIL-STD-810-C, -D, -E and -F.
IC-F1000D / IC-F2000D
Transmitter
Output power
IC-F1000D
5W, 2W, 1W (Hi, L2, L1) IC-F2000D
4W, 2W, 1W (Hi, L2, L1)
Max. frequency deviation ± 5.0kHz/±2.5kHz (Wide/Narrow)
Frequency stability ±1.0ppm
Spurious emissions 70dB min.
FM hum and noise
IC-F1000D
46/40dB typ. (Wide/Narrow) IC-F2000D
50/44dB typ. (W/N)
Audio harmonic distortion
IC-F1000D
2.0%/1.1% typ. (W/N)
(AF 1kHz 40% deviation) IC-F2000D
1.0%/1.5% typ. (W/N)
(AF 1kHz 40% deviation)
FSK error 5.0% max.
Ext. microphone connector 3-conductor 2.5 (d) mm (1⁄10")⁄2.2kΩ
Receiver
Sensitivity
(at 12dB SINAD)
(at 5% BER)
IC-F1000D
0.21μV typ. (Analog)(W/N)
–8dBμV emf typ. (Digital) IC-F2000D
0.24μV typ. (Analog)(W/N)
–8dBμV emf typ. (Digital)
Adjacent channel selectivity
IC-F1000D
77/69/59dB typ. (W/N/D) IC-F2000D
75/69/58dB typ. (W/N/D)
Spurious response 80dB min.
Intermodulation
IC-F1000D
75/75/71dB typ. (W/N/D) IC-F2000D
75/75/70dB typ. (W/N/D)
Hum and noise
IC-F1000D
47/43dB typ. (W/N) IC-F2000D
47/42dB typ. (W/N)
Ext. speaker connector 2-conductor 3.5 (d) mm (1⁄8″)/8Ω
Audio output power (at 5% distortion)
Internal SP (w/12Ω load)
External SP (w/8Ω load)
800mW typ. (at 5% distortion)
400mW typ. (at 5% distortion)
Measurements made in accordance with TIA-603.
All stated specifications are subject to change without notice or obligation.
* 25kHz bandwidth is no longer available for FCC Part 90 licensees for USA versions.
Ask your dealer if you need 25kHz bandwidth.
Ingress Protection Standard
Dust & Water IP67 (Dust-tight and waterproof protection)
